Piston diameter: 18 mm
Type code: SLG
Cushioning: Elastic cushioning rings/pads at both ends: Pneumatic shock absorber, hard characteristic curve
Mounting position: Any
Guide: Recirculating ball bearing guide
Max. number of intermediate positions: 4
Driver principle: Positive locking (slot)
Position sensing: For proximity sensor
Variants: Pulling
Operating pressure: 1 bar - 8 bar
Mode of operation: Double-acting
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 1 - Low corrosion stress
Ambient temperature: -10 to 60 Celsius Degree
Theoretical force at 6 bar, retracting: 153 N
Theoretical force at 6 bar, advancing: 153 N
Additional moving mass per 10 mm stroke: 30 g
Alternative connections: See product drawing
Pneumatic connection: M5
Note on materials: Free of copper and PTFE
Cover material: POM
Seals material: TPE-U(PU)
Housing material: Anodized: Aluminum
Festo Air Cylinder SLG-18-300-P-A
