Festo Air Cylinder ADVC-12-30-I-P-A

There is no price at present, you can Request a Quote

Stroke: 10 mm
Piston diameter: 10 mm
Type code: ADVC
Cushioning: Elastic cushioning rings/pads at both ends
Mounting position: Any
Mode of operation: Double-acting
Design: Piston rod: Piston
Position sensing: For proximity sensor
Symbol: 00991217
Operating pressure: 1 bar - 8 bar
Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 1 - Low corrosion stress
Ambient temperature: -20 to 80 Celsius Degree
Theoretical force at 6 bar, retracting: 40 N
Theoretical force at 6 bar, advancing: 47 N
Moving mass: 3.7 g
Product weight: 45 g
Type of mounting: Optionally:: With through-hole: With accessories
Pneumatic connection: M5
Note on materials: Free of copper and PTFE
Cover material: Anodized: Wrought aluminum alloy
Seals material: TPE-U(PU): NBR
Housing material: Anodized: Wrought aluminum alloy
Piston rod material: High-alloy steel
