Turck Sensor BL20-E-8DI-24VDC-P
$ 496 .92
✔ In Stock (Can ship in 5-7 days)
Quantity
MOQ : 1
Payment Methods
Online Support 24/7
12 Months Warranty for New Products
30 Days Money Back Guarantee
Number of channels 8
Admissible range 18…30 VDC
Nominal current from field supply ≤ 2 mA
Power dissipation, typical ≤ 1.5 W
Input type PNP
Low-level signal voltage -30…+5 V
High level signal voltage 11…30 V
Low level signal current -1…+1.5 mA
High level signal current 2…5 mA
Input delay < 0.2 ms
Electrical isolation electronics for the field level
Output connectivity Push-in
Dimensions (W x L x H) 13 x 128.9 x 74.6 mm
Approvals CE, cULus, zone 2, Class I, Div. 2
Ambient temperature 0…+55 °C
Storage temperature -25…+85 °C
Relative humidity 15…95 %, no condensation allowed
Vibration test Acc. to EN 61131
Shock test Acc. to IEC 60068-2-27
Drop and topple Acc. to IEC 60068-2-31
Electromagnetic compatibility Acc. to EN 61131-2
Protection class IP20
MTTF 1421 years acc. to SN 29500 (Ed. 99) 20 °C
